Epson

Epson ColorWorks C6550A

An 8-inch colour label printer with a built-in auto-cutter, for wide GHS drum labels and product labels up to 211.9 mm across.

Colour Label Printers

Model: CW-C6550A
Print method: Serial inkjet, PrecisionCore TFP printhead
Resolution: Up to 1200 x 1200 dpi
Print speed: Up to 85 mm/s (300 x 600 dpi); 49 mm/s at 600 x 600 dpi; at 203.2 mm print width

Download datasheet WhatsApp us

Where it is used

Industrial Manufacturing
Chemicals
Food & FMCG
Product & Item Labels

About the Epson ColorWorks C6550A

The Epson ColorWorks C6550A is an 8-inch (203.2 mm) colour on-demand label printer with a built-in auto-cutter that cuts each label individually or in batches. Its PrecisionCore TFP printhead prints at up to 1200 x 1200 dpi on labels up to 211.9 mm wide, at up to 85 mm per second, with spot colour matching for brand colours.

Its UltraChrome DL pigment inks meet BS 5609 for GHS-compliant chemical drum labels, which often need the full 8-inch width. It takes roll and fanfold media on matte, synthetic, glossy and high-gloss stock, connects over USB and Gigabit Ethernet, and works with SAP and legacy systems through ZPL II commands.

Key points

8-inch (211.9 mm) colour labels, up to 1200 x 1200 dpi
Up to 85 mm/s
Built-in auto-cutter: single labels or batches
UltraChrome DL pigment inks, BS 5609 for GHS labels
ZPL II support for SAP and legacy host systems
USB 2.0 and Gigabit Ethernet

Suitable applications

Wide GHS chemical drum labels
Large product and carton labels
Industrial and compliance labels

Full specification

Epson ColorWorks C6550A datasheet The manufacturer's complete technical specification, as a PDF.

Download datasheet

View full specification

Model: CW-C6550A
Print method: Serial inkjet, PrecisionCore TFP printhead
Resolution: Up to 1200 x 1200 dpi
Print speed: Up to 85 mm/s (300 x 600 dpi); 49 mm/s at 600 x 600 dpi; at 203.2 mm print width
Max. print width: 211.9 mm
Label width: 21.4 ~ 211.9 mm (backing paper 25.4 ~ 215.9 mm)
Media: Roll (continuous with or without black mark; die-cut with gap or black mark) and fanfold (die-cut with black mark); matte, synthetic, glossy, glossy film and high-gloss paper labels
Ink: UltraChrome DL pigment inks: cyan, magenta, yellow, black (SJIC40P); BS 5609 for GHS labels
Cutter: Built-in auto-cutter

1D barcodes: UPC-A, UPC-E, EAN-13, EAN-8, Code 39, ITF, Codabar, Code 93, Code 128, GS1-128, GS1 DataBar
2D codes: PDF417, QR Code, MaxiCode, DataMatrix, Aztec Code, GS1 DataBar stacked, MicroPDF417, Micro QR Code
Interfaces: USB 2.0; Ethernet 10/100/1000; extended D-sub 25-pin
Commands: ZPL II, for SAP and legacy host systems
Display: 2.7" colour LCD
Power: AC 100 ~ 240 V, 50 ~ 60 Hz
Dimensions: 444 x 515 x 326 mm (W x D x H)
Weight: 25.5 kg
Operating conditions: Printing 5 ~ 35 °C, 20 ~ 80% RH (barcode printing 15 ~ 35 °C)
