Unitech PA720T Plus Windows Rugged Tablet

A 10.1-inch Windows 11 rugged tablet on the Qualcomm 6490 platform, with built-in barcode scanning, 5G, eSIM and IP67 sealing.

Rugged Tablets

Model: PA720T Plus Windows (global model RT112 Windows)
Type: 10.1" Windows rugged tablet
Operating system: Windows 11 IoT Enterprise LTSC
Processor: Qualcomm 6490, 64-bit, eight cores up to 2.7 GHz

Download datasheet WhatsApp us

Where it is used

Industrial Manufacturing
Warehousing
Retail
Healthcare
Hospitality

About the Unitech PA720T Plus Windows Rugged Tablet

The Unitech PA720T Plus Windows is a 10.1-inch rugged tablet running Windows 11 on the Qualcomm 6490 5G IoT platform, with eight cores up to 2.7 GHz, 8 GB of RAM and 128 GB of storage. It runs the full Windows experience with the energy efficiency of an Arm processor and long-term lifecycle support.

Two scan keys read 1D, 2D and postal barcodes. Wi-Fi 6E with fast roaming, Bluetooth 5.2 and optional 5G with eSIM or nano SIM keep it connected, and switching networks takes a QR code or activation code. It is 690 g and 12 mm, sealed to IP67, tested to MIL-STD-810H and built to survive 1.5 m drops, and its 450-nit screen works with wet fingers and gloves up to 4 mm thick. The 8,800 mAh battery is removable.

Key points

Windows 11 on the Qualcomm 6490 5G IoT platform
Built-in 1D/2D barcode scanning with 2 scan keys
5G with eSIM, Wi-Fi 6E and Bluetooth 5.2
Touch works with gloves up to 4 mm and wet fingers
IP67, 1.5 m drop and MIL-STD-810H
690 g, 12 mm; 8,800 mAh removable battery

Suitable applications

Warehouse and manufacturing systems that run on Windows
Retail and hospitality order taking
Healthcare records at the bedside or ward
Field service and delivery
Forklift and vehicle use with the vehicle cradle

Full specification

Unitech PA720T Plus Windows Rugged Tablet datasheet The manufacturer's complete technical specification, as a PDF.

Download datasheet

View full specification

Model: PA720T Plus Windows (global model RT112 Windows)
Type: 10.1" Windows rugged tablet
Operating system: Windows 11 IoT Enterprise LTSC
Processor: Qualcomm 6490, 64-bit, eight cores up to 2.7 GHz
Memory: 8 GB RAM + 128 GB flash
AI: 6th Gen Qualcomm AI Engine
Security: Qualcomm Trusted Execution Environment (TEE)
1D codes: UPC/EAN/JAN, Code 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Discrete 2 of 5, Codabar (NW-7), MSI, Chinese 2 of 5, Matrix 2 of 5, inverse 1D, GS1 DataBar, composite codes
2D codes: QR Code, Data Matrix, Aztec Code, PDF417, Macro PDF417, MicroPDF417, MaxiCode, Codablock A and F, GS1 Composite, Han Xin
Postal codes: Australian, British, Canadian, Japanese, KIX (Netherlands) and Korea Post, InfoMail, Intelligent Mail, Planet Code, Postnet
Display: 10.1" LCD, 1920 x 1200, 450 nits, Gorilla Glass
Touch: Capacitive multi-touch; stylus, wet-finger and glove (up to 4 mm thick) compatible
Rear camera: 13 MP with auto-focus and LED flash
Front camera: 5 MP fixed focus
Buttons: 6 physical buttons: power, volume up and down, 2 scan keys, 1 programmable key
Indicators: LEDs, vibrator
Bluetooth: Bluetooth 5.2
Wi-Fi: Wi-Fi 6E, 2.4 / 5 / 6 GHz, dual-band simultaneous; IEEE 802.11a/b/g/n/ac/ax/d/h/i/k/r/v, 2x2 MU-MIMO
5G (optional): 5G FR1 sub-6 GHz: n1/n2/n3/n5/n28/n41/n48/n66/n71/n77/n78/n79, 4x4 MIMO

4G LTE (optional): FDD bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 28, 66, 71; TDD bands 38, 39, 40, 41, 48. Data, SMS and voice
3G / 2G (optional): UMTS/HSPA+ bands 1, 2, 5, 8; GSM/GPRS/EDGE 850/900/1800/1900 MHz
GPS: GPS, BeiDou, Glonass, Galileo, QZSS and SBAS (WWAN models)
Sensors: Gyroscope, accelerometer, e-compass, light and proximity sensors
USB: USB 3.1 Type-C
Docking: Pogo pins
Audio: Dual speakers, 2 noise-cancelling microphones
Battery: 8,800 mAh, removable
Dimensions: 260 x 165 x 12 mm
Weight: 690 g
Drop: 1.5 m onto concrete
IP rating: IP67 (dust tight; 1 m of water for up to 30 minutes)
Vibration and shock: MIL-STD-810H, Method 516.8, Procedure IV
Operating temperature: -20 ~ 55 °C
Storage temperature: -40 ~ 70 °C
In the box: Tablet, battery pack, USB-C adaptor
Accessories: Rotatable hand strap, shoulder strap, screen protector, office cradle, vehicle cradle, 5.5 mm capacitive stylus with coil strap
SIM and storage: eSIM x 1, nano SIM x 1, microSD x 1
Humidity: 5 ~ 95% non-condensing
