TSC Printronix T4000 RFID

A compact 4 inch printer that encodes and prints UHF RFID labels.

Industrial RFID Printers

Resolution
203 dpi or 300 dpi
Max. Print Speed
12 ips at 203 dpi, 10 ips at 300 dpi
Max. Print Width
4.1" (104 mm)
Media Width
Min 1" (25.4 mm), max 4.72" (120 mm)
Download datasheet

Where it is used

  • Industrial Manufacturing
  • Logistics & Courier
  • Warehousing
  • Track & Trace

About the TSC Printronix T4000 RFID

The TSC T4000 RFID encodes UHF RFID labels and prints them in one pass, for cartons and pallets moving through a supply chain. It checks every tag it writes, and overstrikes and reprints any that fail.

It is the RFID version of the compact T4000, with the same steel enclosure, 203 or 300 dpi printing and up to 12 inches per second.

Key points

  • Encodes and prints UHF RFID labels in one pass
  • Verifies each tag and reprints any that fail
  • Records encoding results for traceability
  • 203 or 300 dpi; up to 12 ips at 203 dpi
  • Ethernet, RS-232 and USB; optional Wi-Fi and Bluetooth 5.0
  • Steel enclosure with bifold media door

Suitable applications

  • Manufacturing and work in progress
  • Warehouse and order fulfilment
  • RFID on-metal tags
  • RFID labels and tags
  • Shipping and receiving labels

See the TSC Printronix T4000 RFID in action

Full specification

TSC Printronix T4000 RFID datasheet The manufacturer's complete technical specification, as a PDF.
Download datasheet
View full specification
Resolution
203 dpi or 300 dpi
Max. Print Speed
12 ips at 203 dpi, 10 ips at 300 dpi
Max. Print Width
4.1" (104 mm)
Media Width
Min 1" (25.4 mm), max 4.72" (120 mm)
RFID
RAIN UHF passive (GS1 EPC Gen2 v2 / ISO 18000-63)
RFID Tag Thickness
Up to 0.05" (1.2 mm) on-metal tags
Ribbon Length
450 metres
Memory
128 MB flash, 128 MB DDR
Interfaces
RS-232 serial, USB and Ethernet 10/100 as standard; Wi-Fi and MFi Bluetooth 5.0 optional
Construction
Steel enclosure with bifold media door

Want a price on the TSC Printronix T4000 RFID?

Tell us the application and the volumes, and our team will quote the printer, the labels and the support together.
