TSC RE310 / RE300

A 3-inch (72 mm print width) mobile printer for receipts and labels, at 203 dpi and up to 4 inches per second.

Mobile Barcode Printers

Resolution: 203 dpi (8 dots/mm)
Print Method: Direct thermal only
Display: LCD with buttons
Hardwire Connectivity: USB

Download datasheet WhatsApp us

Where it is used

Industrial Manufacturing
Logistics & Courier
Warehousing
Retail
Government & Compliance
Hospitality
Product & Item Labels
Receipts

About the TSC RE310 / RE300

The TSC RE310 and RE300 are 3 inch direct thermal mobile printers for receipts, delivery slips and shelf or item labels printed where the work is done. Both print at 203 dpi and up to 4 inches per second.

The RE310 adds Wi-Fi alongside Bluetooth and has a rubber over-moulded casing; the RE300 connects over Bluetooth. Both also connect by USB.

Key points

3 inch direct thermal printing at 203 dpi
Up to 4 ips print speed
Bluetooth on both; Wi-Fi on the RE310
Prints receipts and labels
Rubber over-moulded casing on the RE310
TSPL, EPL2, ZPL2, CPCL or ESC/POS command languages

Suitable applications

Field service and citations
Hospitality and ticketing
Manufacturing and work in progress
Printing on the move
Retail labelling
Transport and logistics
Warehouse and order fulfilment
Product and item labels
Receipts and delivery slips
Shipping and receiving labels

See the TSC RE310 / RE300 in action

Full specification

TSC RE310 / RE300 datasheet The manufacturer's complete technical specification, as a PDF.

Download datasheet

View full specification

Resolution: 203 dpi (8 dots/mm)
Print Method: Direct thermal only
Display: LCD with buttons
Hardwire Connectivity: USB
Wireless Connectivity: Bluetooth, Wi-Fi with Bluetooth (RE310) / Bluetooth (RE300)
Type: Mobile
Max. Print Speed: Up to 4 ips (102 mm/s)
Max. Print Width: 2.83" (72 mm)
Max. Print Length: 110" (2,794 mm)

RAM: 64 MB SDRAM
Flash: 16 MB
Internal Label Capacity: 2" (51mm) OD (RE310) / 1.96" (50 mm) OD (RE300)
Max. Media Width: 0.79"-3.15" (20 mm-80 mm) with liner (RE310) / 1"-3.15" (25.4 mm-80 mm) with liner (RE300)
Ribbon & Media Type: Receipt paper, receipt paper with black mark in printing side or backside, label
Media Core Diameter: Standard: 0.5" (12.7 mm), Optional: 0.75'' (19.1 mm) (RE310) / 0.5" (12.7 mm) (RE300)
Min. Label Length: 0.59" (15 mm)
Construction: Plastic with rubber over-molded construction (RE310) / Plastic (RE300)
Programming Languages: TSPL-EZC (EPL2, ZPL2, CPCL), or ESC-POS
